Ceramic Fiber Paper

Product Overview

TOPWOOL Ceramic Fiber Paper

TOPWOOL ceramic fiber paper is a lightweight, asbestos-free refractory material processed from a blend of high-purity alumina-silica fibers into a highly flexible, uniform sheet. Excellent slag-elimination technology is used, and a small amount of binder is added to keep the paper flexible and reduce off-gassing and odour during use.

It offers excellent thermal insulation and construction performance, is suitable for deep processing such as multi-layer composites and punching, and resists molten metal infiltration — making it ideal for casting washer separation in the construction and glass industries.

Asbestos-free High flexibility Excellent electrical insulation Resists molten infiltration

Size & Specifications

Available Sizes & Uses

Roll Sizes

Length × thickness: 60 m × 1 mm, 30 m × 2 mm, 20 m × 3 mm, 15 m × 4 mm, 12 m × 5 mm, 10 m × 6 mm
Width: 610 mm or 1220 mm
Other sizes available on request

Typical Uses

Industrial insulation, sealing and anti-corrosion
Insulation for instruments and heating elements
Automotive and aerospace insulation
Expansion joint filling
Molten metal sealing gaskets
Fireproof material and glass-fiber substitute

Technical Data

Grade Performance

Property	1260 STD	1400 HA
Classification temperature (°C)	1050	1200
Density (kg/m³)	150–230	150–230
Thermal conductivity	0.045–0.060 W/(m·K) @200°C	—

We supply 1260 STD and 1400 HA grades. Values are indicative.
